Quantabio – qPCR Instrumentation

  • SINGAPORE

    DKSH Singapore Pte Ltd
    625 Lorong 4 Toa Payoh, #03-00
    319519 Singapore
    Singapore

    +65 6471 1466

    Email

  • qPCR Instrumentation Brochure


Q uses a patented magnetic induction technology to rapidly heat samples coupled with fan forced air for cooling to acquire data in only 25 minutes. Available as a 4 channel model, the robust optical system acquires all channels simultaneously and allows for running the fastest multiplexed assays.

Q is exceptionally portable and versatile, without the need for calibration. It scales efficiently, handling up to 48 samples per run, and multiple units can connect wirelessly to a single computer via Bluetooth for processing up to 480 samples simultaneously.

Q’s distinctive spinning aluminum rotor ensures precise temperature control (± 0.05°C), outperforming traditional block-based thermal cyclers with multiple peltier heating blocks that may cause sample variations. This innovation enhances reproducibility and repeatability and enables the detection of 2-fold gene expression differences and precise identification of class IV SNP’s with 0.1°C melt temperature resolution.

Technical Specifications

PhysicalHeight5.1 in
Width5.9 in
Length5.9 in
Weight4.5 lbs
Thermal PerformanceTemperature Accuracy±0.25°C
Temperature Uniformity±0.05°C
Ramp RatesHeating 4°C/s
Cooling 3°C/sCooling 3°C/s
Temperature Input Range40 – 99°C
Reaction TubesSamples per Instrument48
Reaction Volume Range5 – 30µL

Additional Product Information

ProductKit SizeOrder Code
Q – qPCR InstrumentQ 2-channel qPCR InstrumentOrder (95900-2C)
Q 4-channel qPCR InstrumentOrder (95900-4C)
HRM License for Q qPCR Instrument1 HRM LicenseOrder (95915-20)
Q Extended Warranty SILVERQ Extended Warranty SILVEROrder (95900-WSIL)
Q Extended Warranty GOLDQ Extended Warranty GOLDOrder (95900-WGOL)
Q Tubes & Caps (20 racks/box)Q Tubes & Caps (20 racks/box)Order (95910-20)

Key Features

  • Ultra-Fast Data Acquisition

35 cycles in 25 minutes

  • Unrivaled Performance

Detect 2-fold expression level differences

  • Portable & Compact

4.5 lbs – transport without ever calibrating

  • Scalable & Wireless

Connect up to 10 instruments (48 samples/instrument)

  • Magnetic Induction Technology

Eliminate variability vs block-based cyclers

Q is intended for molecular biology applications. This product is not intended for the diagnosis, prevention or treatment of a disease.

Brand

Quantabio

Quantabio is a leading provider of advanced DNA and RNA amplification reagents for the most demanding molecular testing applications in applied, translational, and life science research. Our team leverages decades of experience in developing pioneering amplification technologies to deliver cutting-edge products to researchers focused on critical cloning, PCR, qPCR, and Next-Generation Sequencing (NGS) applications. Based in Beverly, Massachusetts, Quantabio offers a growing portfolio of products through its international sales operations, as well as a global network of distributors and commercial service providers.
