Lighthouse – Environmental Sensor – TRH
The Remote TRH sensor uses the latest sensor technology which offers long-term stability and resistance against pollutants. With NIST Traceable multipoint calibration and IP65/NEMA 4 rated enclosure, the Remote TRH is ideal for cleanroom applications. Using this latest sensor technology, the sensor is available in two models TRH-03-25 and TRH-02-15.
The TRH-02-15 is available with a display option with ±0.2°C (0.36°F) and ±1.5% RH accuracy. The Remote sensor uses the latest sensor technology which offers long-term stability and resistance against pollutants. The enclosure is IP65/NEMA 4 rated and ideal for cleanroom applications.
Key Features
- Range 10-100% RH, -15 to +60°C
- Accuracy ±0.3°C (0.54°F) and ±2.5% RH
- (incl. hysteresis, non-linearity and repeatability)
- Analog Output ( 4 – 20-mA)
- Enhanced sensor protection
- Simple on-site installation
- Mounting Options: Wall mounted, Duct or Remote
- Cleanroom wipe down
- IP65 / NEMA 4 enclosure
- 2 year warranty
Available Models
The Remote TRH-03-25 Sensor comes with ±0.3°C (0.54°F) and ±2.5% RH accuracy.
Key Features
- Range 10-100% RH, -15 to +60°C
- Accuracy ±0.3°C (0.54°F) and ±2.5% RH
- (incl. hysteresis, non-linearity and repeatability)
- Analog Output ( 4 – 20-mA)
- Enhanced sensor protection
- Simple on-site installation
- Mounting Options: Wall mounted, Duct or Remote
- Cleanroom wipe down
- IP65 / NEMA 4 enclosure
- 2 year warranty
The Remote TRH-02-15 Sensor comes with ±0.2°C (0.36°F) and ±1.5% RH accuracy.
Key Features
- Range 0-100% RH, -40 to +60°C
- Accuracy ±0.2°C (0.36°F) and ±1.5% RH
- (incl. hysteresis, non-linearity and repeatability)
- Analog Output ( 4 – 20-mA)
- Enhanced sensor protection
- Simple on-site installation
- Mounting Options: Wall mounted, Duct or Remote
- Cleanroom wipe down
- IP65 / NEMA 4 enclosure
- Optional LCD display
- 2 year warranty
Key Industries
- Aerospace
- Environmental
- Medical
- Pharmaceutical
- Powders & Pigments / Coating
- Semiconductor, Solar & Electronics
Brand
Lighthouse has the most complete line of particle counting and contamination monitoring solutions available. Including of Airborne particle counters, Liquid particle counters, Microbial samplers, Total organic carbon analyzers, and Facility monitoring systems.
