Lighthouse – Airborne Particle Characterization – Real Time Remote with Pump
-
SINGAPORE
DKSH Singapore Pte Ltd
625 Lorong 4 Toa Payoh, #03-00
319519 Singapore
Singapore
Real Time Remote P models use an internal vacuum source and thus their compact size means they can be installed where space is at a premium.
Real Time Remote PN models use a built-in vacuum pump and flow control system to insure accurate and reliable sensor performance. PN models are also designed to meet the stringent requirements of today’s aseptic processing applications.
The image of the Real Time Remote with Pump shown is the model Remote 5104P, which is just one of the many configurations available for Real Time Remote with Pump models.
Below is the list of all available models of Real Time Remote with Pump.
Available Models
Incorporating the latest in laser optical particle counting technology, Lighthouse designed the Remote 2014P airborne particle counter with pump, for continuous trouble free operation.
With a minimum sensitivity of 0.2 µm and a flow rate of 0.1 CFM (2.83 LPM), the Remote 2014P provides real-time continuous data collection at a cost-effective price per point. Using an internal vacuum source, the compact Remote 2014P particle counter can be installed where space is at a premium.
The Remote 2014P will integrate seamlessly into large facility monitoring and management systems and transfer up to 6 channels of simultaneous particle count data using RS-485 Modbus.
Key Features
- 0.2 – 2μm Range
- 0.1 CFM (2.83 LPM) Flow Rate with Internal Pump
- Up to 6 Channels of Simultaneous Data
- Meets JIS Standards and ISO 21501-4 Standards
- Compact Size
- Stainless Steel Enclosure
- Up to Four 4-20 mA Inputs (30 mW)
- LED Status Indicators
- External Alarm Connector
- RS-485 Modbus
- Facility Monitoring System Interface
- Flow-controlled Internal Vacuum Pump
- Designed for Reliability
Incorporating the latest in laser optical particle counting technology, Lighthouse designed the Remote 3014P airborne particle counter with pump, for continuous trouble free operation.
With a minimum sensitivity of 0.3 µm and a flow rate of 0.1 CFM (2.83 LPM), the Remote 3014P provides real-time continuous data collection at a cost-effective price per point. Using an internal vacuum source, the compact Remote 3104P particle counter can be installed where space is at a premium.
The Remote 3014P will integrate seamlessly into large facility monitoring and management systems and transfer up to 6 channels of simultaneous particle count data using RS-485 Modbus.
Key Features
- 0.3 – 25μm Range
- 1.0 CFM (28.3 LPM) Flow Rate with Internal Pump
- Up to 6 Channels of Simultaneous Data
- Meets JIS Standards and ISO 21501-4 Standards
- Compact Size
- Stainless Steel Enclosure
- Up to Four 4-20 mA Inputs (30 mW)
- LED Status Indicators
- External Alarm Connector
- RS-485 Modbus
- Facility Monitoring System Interface
- Flow-controlled Internal Vacuum Pump
- Designed for Reliability
Incorporating the latest in laser optical particle counting technology, Lighthouse designed the Remote 3104P airborne particle counter with pump, for continuous trouble free operation.
With a minimum sensitivity of 0.3 µm and a flow rate of 1.0 CFM (28.3 LPM), the Remote 3104P provides real-time continuous data collection at a cost-effective price per point. Using an internal vacuum source, the compact Remote 3104P particle counter can be installed where space is at a premium.
The Remote 3104P will integrate seamlessly into large facility monitoring and management systems and transfer up to 6 channels of simultaneous particle count data using RS-485 Modbus.
Key Features
- 0.3 – 25μm Range
- 1.0 CFM (28.3 LPM) Flow Rate with Internal Pump
- Up to 6 Channels of Simultaneous Data
- Meets JIS Standards and ISO 21501-4 Standards
- Compact Size
- Stainless Steel Enclosure
- Up to Four 4-20 mA Inputs (30 mW)
- LED Status Indicators
- External Alarm Connector
- RS-485 Modbus
- Facility Monitoring System Interface
- Flow-controlled Internal Vacuum Pump
- Designed for Reliability
Incorporating the latest in laser optical particle counting technology, Lighthouse designed the Remote 5014P airborne particle counter with pump, for continuous trouble free operation.
With a minimum sensitivity of 0.5 µm and a flow rate of 0.1 CFM (2.83 LPM), the Remote 5014P provides real-time continuous data collection at a cost-effective price per point. Using an internal vacuum source, the compact Remote 5014P particle counter can be installed where space is at a premium.
The Remote 5014P will integrate seamlessly into large facility monitoring and management systems and transfer up to 6 channels of simultaneous particle count data using RS-485 Modbus.
Key Features
- 0.5 – 25 μm Range
- 0.1 CFM (2.83 LPM) Flow Rate with Internal Pump
- Up to 6 Channels of Simultaneous Data
- Meets JIS Standards and ISO 21501-4 Standards
- Compact Size
- Stainless Steel Enclosure
- Up to Four 4-20 mA Inputs (30 mW)
- LED Status Indicators
- External Alarm Connector
- RS-485 Modbus
- Facility Monitoring System Interface
- Flow-controlled Internal Vacuum Pump
- Designed for Reliability
Incorporating the latest in laser optical particle counting technology, Lighthouse designed the Remote 5104P airborne particle counter with pump, for continuous trouble free operation.
With a minimum sensitivity of 0.5 µm and a flow rate of 1.0 CFM (28.3 LPM), the Remote 5104P provides real-time continuous data collection at a cost-effective price per point. Using an internal vacuum source, the compact Remote 5104P particle counter can be installed where space is at a premium.
The Remote 5104P will integrate seamlessly into large facility monitoring and management systems and transfer up to 6 channels of simultaneous particle count data using RS-485 Modbus.
Key Features
- 0.5 – 25μm Range
- 1.0 CFM (28.3 LPM) Flow Rate with Internal Pump
- Up to 6 Channels of Simultaneous Data
- Meets JIS Standards and ISO 21501-4 Standards
- Compact Size
- Stainless Steel Enclosure
- Up to Four 4-20 mA Inputs (30 mW)
- LED Status Indicators
- External Alarm Connector
- RS-485 Modbus
- Facility Monitoring System Interface
- Flow-controlled Internal Vacuum Pump
- Designed for Reliability
The Remote 5012PN meets the stringent requirements of today’s aseptic processing applications. Incorporating the latest in laser optical particle counting technology, Lighthouse designed the Remote 5012PN for continuous trouble-free operation.
The Remote 5012PN uses a built-in vacuum pump and flow control system to insure accurate and reliable sensor performance.
With a sensitivity of 0.5 micron at a controlled flow rate of 0.1 CFM, the Remote 5012PN provides continuous real-time data at a cost-effective price per point.
The Remote 5012PN integrates seamlessly into large facility monitoring and management systems and transfers up to 2 channels of simultaneous particle count data using 4-20mA output.
Key Features
- Channel sizes: 0.5 – 5.0 µm for GMP Compliance
- 0.1 CFM (2.83 LPM) Flow Rate
- Internal Vacuum Pump with Flow Control
- Up to 2 channels of simultaneous data
- Meets JIS Standards
- NEMA Style 316L Stainless Steel Enclosure or
- NEMA Style Powder-coated Steel Enclosure
- LED Status Indicators
- Interfaces to Facility Monitoring Systems
- 4-20mA Output
- 120 VAC or 24VDC, 100W Models Available
The REMOTE 5014PN meets the stringent requirements of today’s aseptic processing applications. Incorporating the latest laser optical particle counting technology, Lighthouse designed the REMOTE 5014PN for continuous trouble-free operation.
The REMOTE 5014PN uses a built-in vacuum pump and flow control system to insure accurate and reliable sensor performance.
With a sensitivity of 0.5 micron at a controlled flow rate of 0.1 CFM, the REMOTE 5014PN provides continuous real-time data at a cost-effective price per point.
The REMOTE 5014PN integrates seamlessly into large facility monitoring and management systems and transfers up to 2 channels of simultaneous particle count data using RS-485 MODBUS or Ethernet MODBUS TCP.
Key Features
- Channel sizes: 0.5 – 5.0 µm for GMP Compliance
- 0.1 CFM (2.83 LPM) Flow Rate
- Internal Vacuum Pump with Flow Control
- Standard 2 channels of simultaneous data (optinal 4 channels)
- Meets 21501-4 Standards
- NEMA Style 316L Stainless Steel Enclosure or
- NEMA Style Powder-coated Steel Enclosure
- LED Status Indicators
- Interfaces to Facility Monitoring Systems
- RS-485 Modbus ASCII or Ethernet Modbus TCP Output
- 120 VAC or 24VDC, 100W Models Available
The Remote 5102PN meets the stringent requirements of today’s aseptic processing applications. Incorporating the latest in laser optical particle counting technology, Lighthouse designed the Remote 5102PN for continuous trouble-free operation.
The Remote 5102PN uses a built-in vacuum pump and flow control system to insure accurate and reliable sensor performance.
With a sensitivity of 0.5 micron at a controlled flow rate of 1.0CFM, the Remote 5102PN provides continuous real-time data at a cost-effective price per point.
The Remote 5102PN integrates seamlessly into large facility monitoring and management systems and transfers up to 2 channels of simultaneous particle count data using 4-20mA output.
Key Features
- Channel sizes: 0.5 – 5.0 µm for GMP Compliance
- 1.0 CFM (2.83 LPM) Flow Rate
- Internal Vacuum Pump with Flow Control
- Up to 2 channels of simultaneous data
- Meets JIS Standards
- NEMA Style 316L Stainless Steel Enclosure or
- NEMA Style Powder-coated Steel Enclosure
- LED Status Indicators
- Interfaces to Facility Monitoring Systems
- 4-20mA Output
- 120 VAC or 24VDC, 100W Models Available
The Remote 5104PN meets the stringent requirements of today’s aseptic processing applications. Incorporating the latest laser optical particle counting technology, Lighthouse designed the Remote 5104PN for continuous trouble-free operation.
The Remote 5104PN uses a built-in vacuum pump and flow control system to insure accurate and reliable sensor performance.
With a sensitivity of 0.5 micron at a controlled flow rate of 1.0 CFM, the Remote 5104PN provides continuous real-time data at a cost-effective price per point.
The Remote 5104PN integrates seamlessly into large facility monitoring and management systems and transfers up to 2 channels of simultaneous particle count data using RS-485 MODBUS or Ethernet MODBUS TCP.
Key Features
- Channel sizes: 0.5 – 5.0μm for GMP Compliance
- 1.0 CFM (28.3 LPM) Flow Rate
- Internal Vacuum Pump with Flow Control
- Standard 2 Channels of Simultaneous Data (optional 4 channels)
- Meets ISO 21501-4 Standards
- NEMA Style 316L Stainless Steel Enclosure or NEMA Style Powder Coated Steel Enclosure
- LED Status Indicators
- Interfaces to Facility Monitoring Systems
- RS-485 MODBUS ASCII or Ethernet MODBUS TCP Output
- 120VAC or 24VDC, 100W Models Available
Key Industries
- Aerospace
- Environmental
- Medical
- Pharmaceutical
- Powders & Pigments / Coating
- Semiconductor, Solar & Electronics
