Kirsch Blood Plasma Freezer

  • SINGAPORE

    DKSH Singapore Pte Ltd
    625 Lorong 4 Toa Payoh, #03-00
    319519 Singapore
    Singapore

    +65 6471 1466

    Email

KIRSCH is the market leader for pharmaceutical refrigerators and freezers in Germany. Each freezer is particularly made to meet the demanding DIN 58345 regulation. Kirsch products are market leading in temperature stability and quality.

Available Models

Technical Specifications

Capacity170 l
Temperature setting (approx.)-32°C
Voltage220 – 240 V
Frequency50 Hz
Power consumption460 Watt
Normal consumption5,3 KW / 24 h
Overall dimensions incl. distance from wall70 x 77 x 122 (w x d x h in cm)
Interior dimensions55 x 52 x 60 (w x d x h in cm)
Usable dimensions52 x 41 x 47 (w x d x h in cm)
Overall dimensions with door open at 90°70 x 136 (w x d in cm)
Drawer inner dimensions50 x 34 x 10 (w x d x h in cm)
Max. loading capacity per drawer50 kg
Weight92 kg / 105 kg (net / gross)
  • 3 aluminium drawers
  • Comfort controller
  • Micro-processor controlled temperature and thawing
    regulation to maximize temperature stability
  • Battery for power failure alarm
  • Heated door frame
  • Re-circulating air-cooling
  • Optimized ventilation plates to minimize interior temperature differences
  • Rapid defrosting
  • Melt water evaporation
  • Easy accessible control panel with key switch
  • Easy-to-read LED temperature display
  • Optical and acoustical warning including power failure alarm
  • Minimum/maximum temperature memory
  • RS485 interface for computer based temperature documentation
  • Potential free contact for alarm transmission
  • Lockable door

Technical Specifications

Capacity170 l
Temperature setting (approx.)-41°C
Voltage220 – 240 V
Frequency50 Hz
Power consumption460 Watt
Normal consumption5,9 KW / 24 h
Overall dimensions incl. distance from wall70 x 77 x 122 (w x d x h in cm)
Interior dimensions55 x 52 x 60 (w x d x h in cm)
Usable dimensions53 x 37 x 47 (w x d x h in cm)
Overall dimensions with door open at 90°70 x 136 (w x d in cm)
Drawer inner dimensions52 x 32 x 10 (w x d x h in cm)
Max. loading capacity per drawer50 kg
Weight100 kg / 110 kg (net / gross)
  • 3 stainless steel drawers
  • Comfort controller
  • Micro-processor controlled temperature and thawing
    regulation to maximize temperature stability
  • Battery for power failure alarm
  • Heated door frame
  • Re-circulation air-cooling
  • Optimized ventilation plates to minimize interior temperature differences
  • Rapid defrosting
  • Melt water evaporation
  • Easy accessible control panel with key switch
  • Easy-to-read LED temperature display
  • Optical and acoustical warning including power failure alarm
  • Minimum/maximum temperature memory
  • RS485 interface for computer based temperature documentation
  • Potential free contact for alarm transmission
  • Lockable door

Technical Specifications

Capacity300 l
Temperature setting-32°C
Voltage220 – 240 V
Frequency50 Hz
Power consumption490 Watts
Normal consumption6,85 KW / 24 h
Overall dimensions incl. distance from wall74 x 78 x 159 (w x d x h in cm)
Interior dimensions59 x 52 x 95 (w x d x h in cm)
Usable dimensions57 x 42 x 82 (w x d x h in cm)
Overall dimensions with door open at 90°74 x 142 (w x d in cm)
Drawer inner dimensions54 x 37 x 10 (w x d x h in cm)
Loading capacity per drawer50 kg
Weight120 kg / 135 kg (net / gross)
  • 4 aluminium drawers
  • Comfort controller
  • Micro-processor controlled temperature and thawing
    regulation to maximize temperature stability
  • Battery for power failure alarm
  • Heated door frame
  • Re-circulation air-cooling
  • Optimized ventilation plates to minimize interior temperature differences
  • Rapid defrosting
  • Melt water evaporation
  • Height-adjustable drawers
  • Easy accessible control panel with key switch
  • Easy-to-read LED temperature display
  • Optical and acoustical warning including power failure alarm
  • Minimum/maximum temperature memory
  • RS485 interface for computer based temperature documentation
  • Potential free contact for alarm transmission
  • Lockable door

Technical Specifications

Capacity500 l
Temperature setting-32°C
Voltage220 – 240 V
Frequency50 Hz
Power consumption730 Watts
Normal consumption9,8 KW / 24 h
Overall dimensions incl. distance from wall77 x 76 x 193 – 196 (w x d x h in cm)
Interior dimensions62 x 56 x 140 (w x d x h in cm)
Usable dimensions60 x 45 x 127 (w x d x h in cm)
Overall dimensions with door open at 90°77 x 144 (w x d in cm)
Drawer inner dimensions56 x 39 x 10 (w x d x h in cm)
Loading capacity per drawer50 kg
Weight161 kg / 183 kg (net / gross)
  • 4 aluminium drawers
  • Comfort controller
  • Micro-processor controlled temperature and thawing
    regulation to maximize temperature stability
  • Battery for power failure alarm
  • Heated door frame
  • Re-circulation air-cooling
  • Optimized ventilation plates to minimize interior temperature differences
  • Rapid defrosting
  • Melt water evaporation
  • Height-adjustable drawers
  • Easy accessible control panel with key switch
  • Easy-to-read LED temperature display
  • Optical and acoustical warning including power failure alarm
  • Minimum/maximum temperature memory
  • RS485 interface for computer based temperature documentation
  • Potential free contact for alarm transmission
  • Lockable door

Technical Specifications

Capacity650 l
Temperature setting-41°C
Voltage220 – 240 V
Frequency50 Hz
Power consumption960 Watts
Normal consumption11,1 KW / 24 h
Overall dimensions incl. distance from wall83 x 102 x 197 (w x d x h in cm)
Interior dimensions62 x 76 x 131 (w x d x h in cm)
Usable dimensions59 x 65 x 118 (w x d x h in cm)
Overall dimensions with door open at 90°86 x 177 (w x d in cm)
Drawer inner dimensions, upper drawer59 x 56 x 22 (w x d x h in cm)
Drawer inner dimensions, 4 drawers below59 x 62 x 22 (w x d x h in cm)
Loading capacity per drawer50 kg
Weight220 kg / 260 kg (net / gross)
  • 5 stainless steel drawers
  • Comfort controller
  • Micro-processor controlled temperature and thawing
    regulation to maximize temperature stability
  • Battery for power failure alarm
  • Heated door frame
  • Re-circulation air-cooling
  • Optimized ventilation plates to minimize interior temperature differences
  • Rapid defrosting
  • Melt water evaporation
  • Easy accessible control panel with key switch
  • Easy-to-read LED temperature display
  • Optical and acoustical warning including power failure alarm
  • Minimum/maximum temperature memory
  • RS485 interface for computer based temperature documentation
  • Potential free contact for alarm transmission
  • Lockable door

Technical Specifications

Capacity300 l
Temperature setting-32°C
Voltage220 – 240 V
Frequency50 Hz
Power consumption490 Watts
Normal consumption6,85 KW / 24 h
Overall dimensions incl. distance from wall74 x 78 x 159 (w x d x h in cm)
Interior dimensions59 x 52 x 95 (w x d x h in cm)
Usable dimensions57 x 42 x 82 (w x d x h in cm)
Overall dimensions with door open at 90°74 x 142 (w x d in cm)
Drawer inner dimensions54 x 37 x 10 (w x d x h in cm)
Loading capacity per drawer50 kg
Weight120 kg / 135 kg (net / gross)
  • 5 aluminium drawers
  • Comfort controller
  • Micro-processor controlled temperature and thawing
    regulation to maximize temperature stability
  • Battery for power failure alarm
  • Heated door frame
  • Re-circulation air-cooling
  • Optimized ventilation plates to minimize interior temperature differences
  • Rapid defrosting
  • Melt water evaporation
  • Height-adjustable drawers
  • Easy accessible control panel with key switch
  • Easy-to-read LED temperature display
  • Optical and acoustical warning including power failure alarm
  • Minimum/maximum temperature memory
  • RS485 interface for computer based temperature documentation
  • Potential free contact for alarm transmission
  • Lockable door

Key Features

Advantages

  • DIN 58375 compliant
  • Aluminium / stainless steel drawers
  • Comfort controller
  • Micro-processor controlled temperature and thawing regulation to maximize
    temperature stability
  • Battery for power failure alarm
  • Heated door frame
  • Re-circulating air cooling
  • Optimized ventilation plates to minimize interior temperature differences
  • Rapid defrosting
  • Melt water evaporation
  • Height-adjustable drawers*
  • Easy accessible control panel with key switch
  • Easy-to-read LED temperature display
  • Optical and acoustical warning including power failure alarm
  • Minimum/maximum temperature memory
  • RS-485 interface for computer based temperature documentation
  • Potential free contact for alarm transmission.

*Except FROSTER-BL-178, FROSTER-BL-180 and FROSTER-BL-650.

Key Industries

  • Biopharmaceutical and Biotechnology
  • Cosmetics & Personal Care
  • Food & Beverage
  • Medical
  • Pharmaceutical

Brand

Philipp Kirsch

KIRSCH- Reliable cooling in labs and health care. Since 1865 our name has been synonymous with high-quality products which meet the most demanding standards and provide maximum reliability. Our products are being used in the whole world – in tropical countries as well as far up north. All product innovations benefit from the experience and expertise which we have been gathering over all those years.
