Haas – CNC Lathes, 2 Axis – ST-40 Series
The Haas ST-40 Series high-performance turning centers provide heavy cutting ability, extreme rigidity, and high thermal stability. These large-capacity machines offer the best combination of performance and value in their class, and are available with a wide selection of high-productivity options, including 6 000-rpm live tooling and C axis.
The long-bed ST-40L provides nearly double the cutting length for turning and boring long shafts and tubing.
Key Features
- Generous Work Envelope: Handles parts up to 25.5″ x 44″ with a 4.0″ bar capacity.
- Powerful Spindle: Equipped with a 40 hp vector drive, 2400 rpm spindle, and A2-8 spindle nose.
- Robust Turret System: Features a 12-station bolt-on turret for versatile tooling options.
Available Models
Technical Specifications
CNC Lathe; 25.5″ x 44″ (648 x 1118 mm) max capacity, 4.0″ (102 mm) bar, 34.5″ (876 mm) swing, 40 hp (30 kW) vector drive, 2400 rpm, 2-speed gearbox, A2-8 spindle, 15″ (381 mm) chuck, 12-station bolt-on turret, 15″ color LCD monitor, memory lock keyswitch, USB port, color remote jog handle and rigid tapping. Standard toolholder kit included with BOT or Hybrid turret.
Technical Specifications
CNC Lathe; 25.5″ x 80″ (648 x 2032 mm) max capacity, 4.0″ (102 mm) bar, 34.5″ (876 mm) swing, 40 hp (30 kW) vector drive, 2400 rpm, 2-speed gearbox, A2-8 spindle, 15″ (381 mm) chuck, 12-station bolt-on turret, programmable servo tailstock, 15″ color LCD monitor, memory lock keyswitch, USB port, color remote jog handle and rigid tapping. Standard toolholder kit included with BOT or Hybrid turret.
Haas ST-40 Demo
Key Industries
- Aerospace
- Automotive
- Defense
- Die & Mould
- Education & Academics
- Electronics
- Machinery & Manufacturing
- Medical
- Mining & Minerals
- Oil & Gas
- Semiconductor, Solar & Electronics
- Shipbuilding
Brand
Haas Automation is the largest machine tool builder in the western world, manufacturing a complete line of CNC vertical machining centers, horizontal machining centers, CNC lathes, and rotary products. High-quality Haas machines are engineered for simple maintenance, easy setup, and low-cost operation.
