Daihan – Digital High Temperature Oil Bath
Digital High Temperature Oil Bath, “WHB”, 6-/11-/22-Lit.
- With certificate & traceability : controlled by serial number, certificate, delivery-information, and traceable data base system
- Corrosion resistant 304 stainless steel bath having 1.2mm thickness and ceramic fiber insulator of 50mm thickness are used for an application at high temperature
- Digital fuzzy control system implementing superior temperature accuracy
- Patented jog-shuttle control system and digital LCD with back-light function
- CE certified
- PL(Product Liability) insurance
Available Models
Technical Specifications
| Capacity | 6 Lit. |
| Temp. Range & Accuracy | Ambient + 5 ℃ to 250 ℃, ±1.5℃ |
| Temp. Uniformity & Probe | ±3.0℃, PT100 |
| Heating Power | 1.5 kW |
| Drain Valve | Mounted |
| Dimension (w×d×h) | Effective Space – 270×180×h110 mm ; Internal – 270×180×h150 mm ; External – 425×305×h340 mm |
| Power Supply & Cord/Plug | 1 Phase, AC 120 V, 60 Hz or 230 V, 50 / 60 Hz |
Technical Specifications
| Capacity | 11 Lit. |
| Temp. Range & Accuracy | Ambient + 5 ℃ to 250 ℃, ±1.5℃ |
| Temp. Uniformity & Probe | ±3.0℃, PT100 |
| Heating Power | 2.0 kW |
| Drain Valve | Mounted |
| Dimension (w×d×h) | Effective Space – 300×250×h110 mm ; Internal – 300×250×h150 mm ; External – 425×375×h340 mm |
| Power Supply & Cord/Plug | 1 Phase, AC 120 V, 60 Hz or 230 V, 50 / 60 Hz |
Technical Specifications
| Capacity | 22 Lit. |
| Temp. Range & Accuracy | Ambient + 5 ℃ to 250 ℃, ±1.5℃ |
| Temp. Uniformity & Probe | ±3.0℃, PT100 |
| Heating Power | 2.5 kW |
| Drain Valve | Mounted |
| Dimension (w×d×h) | Effective Space – 400×300×h140 mm ; Internal – 400×300×h180 mm ; External – 525×425×h370 mm |
| Power Supply & Cord/Plug | 1 Phase, AC 120 V, 60 Hz or 230 V, 50 / 60 Hz |
Key Features
- Corrosion Resistant 304 Stainless steel Bath having 1.2mm Thickness and Ceramic Fiber Insulator of 50mm Thickness are used for an application at High Temperature
- User’s Self-Compensation Function to Control Difference between Real Temperature and Indicated Temperature
- Storage Function for the Set Values of Temperature and Timer
- Alarm Function : Error Status and Timer-end.
- Digital Timer Function : ‘Delay Time’ and ‘Operation Time’ can be Controlled.
- Locking Mode Supported for Experimental Safety (Input to Jog-Shuttle can be Disabled)
Key Industries
- Biopharmaceutical and Biotechnology
- Chemical
- Education & Academics
- Food & Beverage
- Medical
- Pharmaceutical
