The HAIMER 3D-Sensors are very precise and wide-ranging measurement devices for milling and EDM machines (isolated probe tip). They are clamped into a tool holder and inserted into a milling spindle and make it possible to position the spindle axis exactly on the edges of the workpiece. This allows for zeros to be set and the length to be measured quickly and easily. You may approach in any direction (X-, Y-, Z-Axis). When the dial gage shows zero, the spindle axis is exactly on the workpiece edge.

Only the HAIMER 3D-Sensor allows for the edge to be found on the first attempt. No calculating of the probe’s ball diameter is necessary – just Zero it out! Problems with mathematics or calculations are eliminated, allowing for fewer operator errors.

By using the HAIMER Centro centering bores and arbors is quick and precise.

HAIMER Microset tool presetting technology complements the existing HAIMER portfolio of an extensive tool holding program, shrinking and balancing technology, tool management logistics as well as 3D measuring devices and solid carbide cutting tools. As a result, we can offer you a perfectly matching product range from a single source.

In addition to precision, speed and reliability, the UNO series also includes numerous features in terms of its equipment. The new design and improved ergonomics set new standards. High quality components are used, e.g. from SMC, Bosch, Heidenhain, IDS.

The Basic Line is the economical entrance into inductive shrink fit technology. the power electronics enables problem free shrinking. The mechanical construction of the equipment has, on the other hand, been kept deliberately simple and functional. there are just single chuck solutions.

The Basic Line is ideal for the price-conscious user, who only wants to shrink a few tools on a daily basis.

For micro machining purpose the special horizontal shrink fit unit Power Clamp Nano is part of the program- It combines perfectly easy tool handling of small diameters and fast tool exchange.

The Profi Line offers the full range of performance and is unbeatable in efficiency. High performance coils, contact cooling and rotary table guarantee simultaneous shrinking and cooling in record time. No wishes remain unfulfilled.

The machines of the Profi Line work both the standard coils and the intelligent and comfortable NG coils. Of course, the equipment recognizes each coil and chooses the correct shrink fit parameters automatically.

The shrink fir units of the Profi Line form a modular system. The start-up machine Power Clamp Economic can gradually be upgraded to the high performance Power Clamp Comfort NG.

The high-end shrink fit machine Power Clamp Premium Plus complements the Profi Line. It stands for absolute process reliability with two separate electronic units and two coils.

The interface DIN 69893 has become the new standard for machining centres. The holder is clamped via its taper with flange contact surface. By doing so, a highly accurate centring and fixed axial position of the holder in the spindle is granted with a high repetitive accuracy when exchanging the tools.

In the DIN 69893-1 HSK-A interface design an additional torque transmission takes place at the taper shank with drive keys. DIN 69893 HSK-A/HSK-E/HSK-F is mainly used in high-speed machining.

The traditional interface for milling spindles ASME B5.50 distinguishes itself through its extremely robust design. Its field of application ranges from fine machining to heavy duty roughing.

The tool holder is pulled in the milling spindle with the help of an additional pull stud. The centering takes place via the taper contact. Therefore, the ASME B5.50 steep taper interface is primarily suitable for applications with a spindle speed of up to 12,000 rpm.

Tool Management Logistics System.

HAIMER tops off its portfolio as a system partner around tool clamping with its Tool Management, the complete solution for tool presetting and administration.

HAIMER backs its workbenches and modules with specific solutions which have grown and matured over the years in their own production. The whole working area is specifically designed for tool storage, assembly and administration. All auxiliary materials are firmly established. All requirements have been thought of for an efficient and ergonomic working for tool management ranging from lighting to the dust bin.

If desired, HAIMER will take over the complete functional design of working areas which focuses on storage, assembly, presetting and administration of tools.

With the Power Mill end mill series, HAIMER can provide its tool holders with a universal solid end milling range for the universal use in different materials.

Besides that, Basic Mill solid carbide end mills are reduced to the basics in terms of product characteristics. Therefore they offer a cost effective alternative compared to our Power Mill solid carbide end mills, while ensuring the same HAIMER quality. Basic Mill solid carbide end mills can be used in almost all materials, especially for roughing and finishing.
